Ladle Shroud

Ladle Shrouds, with a standard oxidation protection liner at the CNT area, are designed to function without pre-heating. This cold-start functionality is guaranteed by a special anti-spalling liner. If needed, then slagline protection can be provided. There is a range of main body material choice depending on the steel composition and desired length of casting sequence. Nitrogen pick-up can be reduced by argon protection, which is provided through a metallic can system.

Ladle Shroud

Anti-Oxidation liner

Against oxygen lancing and other damage to assure excellent collector nozzle fit.

Tempseal Gasket

Provide good connection between collector nozzle and Ladle Shroud.

Body material

Alumina graphite material ensures high mechanical strength.

Y-shape design

And Metallic can Re-Enforcement with build-in Argon Management. Matching the angle of the manipulator, the metallic can will enhance mechanical strength.
The Argon system minimalizes N2/O2 pick-up.

Anti-spalling Liner

High Alumina composition liner. Partly designed for anti-spalling, partly to increase service life and mechanical resistance.

Tundish Flux Resistant material

High Erosion Resistant sleeve section, based on cold start zirconia composition.

Body material

Designed to desired customer casting duration.
